XDMT-OCT3SS-15
Size:
Colour:
Orange
Find a Retailer
Recommended Retail Prices excludes shipping costs, dealer assembly/prep and accessories. Please speak to your nearest store for more information.
Specifications
| Frame Size | 29*15"/29*17"/29*19"/29*21" |
| Frame | XDS X6 6061 Alloy |
| Fork | XDS 140mm w M15 thru axles |
| Rear Shock | Rock Shox Monarch RL-C2 165 x 38 |
| Handlebar | XDS Alloy 31.8 750mm wide |
| Grip | MTB Rubber |
| Stem | XDS Alloy 45mm |
| Seatpost | XDS Alloy 31.6 x 410mm 100mm travle Dropper |
| Seat Clamp | Alloy with Quick Release |
| Saddle | MTB Saddle |
| Left Gear Shifter | N/A |
| Right Gear Shifter | microSHIFT Advent 9 Speed Sl-M819-R |
| Front Derailleur | N/A |
| Rear Derailleur | microSHIFT Advent RD-M6195M 9 Speed |
| Front Brake | Tektro M290 Hydraulic disc with 180mm rotor |
| Rear Brake | Tektro M290 Hydraulic disc with 160mm rotor |
| Freewheel | Microshift CS-H093 11-42t 9 Speed |
| Pedal | MTB Plastic with bearings |
| Chainwheel | Charm FD04S 32T |
| Crank Arm | Alloy 165mm/15" - 170mm/ 17, 19 and 21" |
| Chain | 1/2 x 11/128 x 114L |
| Bottom Bracket | Cartridge |
| Headset | Alloy integrated |
| Front Hub | Alloy 32H with 15mm Boost Quick Release Disc |
| Rear Hub | Alloy 32H Quick Release, Disc, Freehub |
| Spokes | 14G Stainless Steel with brass nipples |
| Tyre | MTB 29 x 2.25 60TPI |
| Rim | XDS X-SX19 32H Alloy |
| Bell | Alloy flick |
Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
Bike Size Guide
| Frame Size Number | 15" | 17" | 19" | 21" |
| Wheel Size | 29" | 29" | 29" | 29" |
| Suggested Height | 160-170 | 170-180 | 180-190 | 190-200 |
| Minimum Suggested Inseam | 77cm | 78cm | 80cm | 85cm |
| A - Seat Tube | 38.1cm | 43.2cm | 48.3cm | 53.3cm |
| B - Seat Tube Angle | 74.6° | 74.6° | 74.6° | 74.6° |
| C - Head Tube Length | 11cm | 11cm | 12cm | 13cm |
| D - Effective Top Tube | 57.6cm | 57.6cm | 59.5cm | 61.5cm |
| E - Chainstay Length | 47cm | 47cm | 47cm | 47cm |
| F - Wheelbase | 114.5cm | 114.5cm | 116.5cm | 118.6cm |
| G - Standover | 75.7cm | 76cm | 78.8cm | 83cm |
