XDSTRIKE4-21GH-17
Size:
Colour:
Green Heron
Find a Retailer
Recommended Retail Prices excludes shipping costs, dealer assembly/prep and accessories. Please speak to your nearest store for more information.
Specifications
| Frame Size | 26/13",15" - 27.5/17",19",21" |
| Frame | XDS X6 6061 Alloy |
| Fork | Suntour XCE-DS, 100mm travel |
| Handlebar | XDS Alloy 31.8 640mm wide |
| Grip | MTB Rubber |
| Stem | XDS Alloy A-Head 70mm |
| Seatpost | XDS Alloy 31.6 x 350mm with clamp |
| Seat Clamp | Alloy 31.8mm with Quick Release |
| Saddle | MTB Saddle |
| Gear Shifter | Shimano M315 Rapidfire, 2 speed |
| Gear Shifter | Shimano M315 Rapidfire, 8 speed |
| Front Derailleur | Shimano Altus M315 front derailleur |
| Rear Derailleur | Shimano TX800SG Rear Derailleur 8-speed |
| Front Brake | Tektro M275 Hydraulic disc with 160mm rota |
| Rear Brake | Tektro M275 Hydraulic disc with 160mm rota |
| Freewheel | Shimano HG318 - 8 Speed Cassette, 11-32t |
| Pedal | MTB Plastic with bearings |
| Chainwheel | Prowheel 22/36T steel rings with Alloy 170mm Cranks |
| Chain | 1/2 x 11/128 x 108L |
| Bottom Bracket | Cartridge |
| Headset | Alloy/Steel integrated |
| Front Hub | Alloy 32H Quick Release Disc |
| Rear Hub | Alloy 32H Quick Release, Disc, Freehub |
| Spokes | 14G Steel with brass nipples |
| Tyre | MTB 26 x 2.10, 27.5 x 2.10 all Black |
| Rim | XDS XV21 32H Alloy |
| Bell | Alloy flick |
| Kickstand | Steel |
Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
Bike Size Guide
| Frame Size Number | 13" | 15" | 17" | 19" | 21" |
| Wheel Size | 26" | 26" | 27.5"c | 27.5" | 27.5" |
| Suggested Height | 160-170cm | 165-175cm | 175-185cm | 185-195cm | 195+cm |
| Minimum Suggested Inseam | 70cm | 74cm | 78cm | 81cm | 84cm |
| A - Seat Tube | 33cm | 38.1cm | 43.2cm | 48.3cm | 53.3cm |
| B - Seat Tube Angle | 73° | 73° | 73° | 73° | 73° |
| C - Head Tube Length | 12.5cm | 12.5cm | 12.5cm | 12.5cm | 12.5cm |
| D - Effective Top Tube | 55.48cm | 55.48cm | 59.6cm | 59.6cm | 59.6cm |
| E - Chainstay length | 43.5cm | 43.5cm | 43.5cm | 43.5cm | 43.5cm |
| F - Wheelbase | 105.72cm | 105.72cm | 109.47cm | 109.47cm | 109.47cm |
| G - Standover | 68cm | 72cm | 76cm | 79cm | 82cm |
