Features
Lightweight Alloy Frame
Reduce resistance and improve your handling with a lightweight 6061 alloy frame.
Shimano Drivetrain
Find the most appropriate gearing ratio for tackling a range of inclines on and off-road with the 8-Speed Shimano Tourney Alfine Internal Hubdrivetrain. Shift gears easily with your Shimano Revo shifter.
Reliable Stopping Power
Come to a comfortable safe stop with reliable front and rear Shimano hydraulic disc brakes.
700c Wide Tyres
Find greater control with more traction with the wide 700x40c tyres.
Specifications
| Frame | Alloy 6061 700C×530mm HT:?50×?44×170mm RC:452mm |
| Fork | Alloy /Steel 700C ?28.6×?25.4×?30×259mm |
| Tyre | 700C×40C WIRE 30TPI |
| Tube | 700C×40C A/V |
| Rim Tape | PVC |
| Rim | XDS Alloy 700C?×19×14G×36H H:18mm |
| Front hub | Alloy KT TC7F 14G×36H×M10×100×108mm |
| Rear Hub | Shimano Alfine KSG70018AL INTERNAL HUB GEAR 8-SPEED FOR DISC, SG-S7001-8, ALFINE, 36H 135X187MM, |
| Internal hub components | Shimano KMMS 700080001 SG-S7000-8, ALFINE, |
| Spoke | SS 14G |
| Chainwheel | Gates 7870050 S150 W/CDN CenterTrack?50T*175MM |
| Freewheel | 78980334 Gates CDN 24T |
| Belt | 95111017 Gates CDN Belt? 120T |
| BB | Steel BC1.37""*24T |
| BB Set | BC1.37""×24T 68mm L:116mm |
| Headset | ?28.6×44×30 H:22.5 |
| Pedal | 9/16 W/Ball |
| Front Brake | Shimano AMT201KLRXRX 145 DISC BRAKE ASSEMBLED SET, BL-MT201(L), BR-MT200(R), BLACK, |
| Rear Brake | Shimano AMT201KFRPRXO75 DISC BRAKE ASSEMBLED SET, BL-MT201(R), BR-MT200(F), BLACK |
| ROTOR | Shimano ROTOR SM-RT54, S 160MM, W/LOCK RING (INTERNAL SERRATION),FOR RESIN PAD |
| R Shifter | Shimano ASLC60008l 149l SHIFT LEVER, SL-C6000-8, NEXUS, REVO SHIFTER |
| Handlebar | W:640mm 5° H?25mm |
| Stem | ?28.6mm E:80mm H:41mm 7° |
| Grip | L/R?130 closed end |
| Bell | Steel/PP |
| Saddle | YBT Black rail/clamp |
| Seatpost | ?27.2×350mm W/O logo |
| Seat Clamp | ?31.8mm W/QR |
Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
