RRP $1,999.00

ICEL-MERGE26MB-17
Size:
Colour: Midnight Black

Features

Bafang 36v 250w Bafang 36v 250w

Bafang 36v 250w Motor

Go further with a Bafang RM G120 250w Electric Motor fitted on the rear hub. Amplify your pedaling power to pick up speed or power through hills with ease to make your cruise or commute effortless.

Lightweight Alloy Lightweight Alloy

Lightweight Alloy Frame

Reduce riding effort through hills and improve your handling with a lightweight 6061 alloy frame.

Shimano Altus 8 Speed Shimano Altus 8 Speed

Shimano Altus 8 Speed Drivetrain

Shift through 8 speeds with the Shimano Altus Rapid Fire Plus drivetrain. You’ll find the perfect gear ratio for whatever incline you come across to keep you climbing consistently.

Double Wall Rims

Double Wall Rims

Trust in the strength of double wall rims. With 26" x 3" tyres, you’ll find excellent maneuverability and traction to keep you in control in uncertain terrains.

Reliable Braking Reliable Braking

Reliable Braking

Stop comfortably and smoothly with front and rear hydraulic Shimano disc brakes. These brakes are simple, reliable, and easy to maintain.

Lithium-Ion Battery with Panasonic Cells

A great electric bike needs a great battery to work. The E-Merge comes with a big 36v 2900mAh Panasonic cell to keep you going and going. Safety tested to strict international standards and comes with intelligent protection board for longevity and durability.

Road Legal & Compliance Road Legal & Compliance

Road Legal & Compliance Tested

For your safety and security, you can be assured that our bike is compliance tested and 100% road legal.

Specifications

FRAME SIZE 26×19"
FRAME Alloy 26×19" H/T:φ50*φ44*200MM, S/T:φ31.8*2.2T,WB:1171.3,RC:500MM W:138
FORK Steel φ25.4*φ28.6*224mm
HANDLEBAR Steel W:630mm*1.6T,64° H=241MM
GRIPS Rubber L/R:120mm Closed End
STEM Alloy φ25.4*180mm,E:90mm,35°
SEAT POST Alloy φ27.2*400mm*2.55T
SEAT CLAMP Alloy φ31.8mm
SADDLE PU Steel ED rail, W/PVC Spring Clip
PEDALS Alloy 9/16″ W/Ball AS
GEAR SHIFTERS Shift Lever, SL-M310, Right 8-Speed 2400MM Stainless Inner W/ Optical Gear Display
REAR DERAILLEUR RD-M310-L, Altus 7/8-Speed Direct Attachment Black
FRONT BRAKES Disc Brake Assembled Set, BL-MT200(R), BR-MT200(F), Black, W/O Adapter, Resin Pad W/O Fin, 950MM Hose
REAR BRAKES Disc Brake Assembled Set, BL-MT200(R), BR-MT200(F), Black, W/O Adapter, Resin Pad W/O Fin, 1650MM Hose
BRAKE LEVERS N/A
FREEWHEEL Steel ACSHG2008232, Cassette Sprocket, CS-HG200-8, 8-Speed, 12-14-16-18-21-24-28-32(BR)
CHAINWHEEL & CRANKS Steel/Alloy 1/2*3/32"*42T*170L,ED Steel Chainwheel, Black Alloy Crank
CHAIN Steel 1/2"*3/32"*130L
CHAINGUARD Steel F Type
BOTTOM BRACKET Steel/Alloy L:68*127.5mm
HEADSET Steel ED,10pcs,φ25.4*φ44*φ30,H:25.5mm
FRONT HUB Alloy M9*13G*36H*100*108, W/QR KT-204Y
SPOKES SS 13G W/14mm Brass Nipple
SPOKES SS 12G W/14mm Brass Nipple
TYRES Rubber 26"*3.0 w/Tube AV
RIMS Alloy 26"*3.0*13G*36H,H:18MM A/V
BELL Alloy/Plastic 22.2MM
KICKSTAND Steel L=310MM
NET WEIGHT 23.35kg

Electrical Components

MOTOR Bafang RMG020.250.D, 26"*36V*250W 25KM/H 12G*36H*138*198MM Cable Length:550mm
BATTERY 2900MAH-18650 10S4P/11.6AH 250W 15A
DISPLAY 36V, 25km/h 1-5 Level
CHARGER 42V-2A/100-240VDC DC2.1*5.5 AU Type
SENSOR Hall Sensor, Cable Length: 250MM
CONTROLLER LSW-1520-17M, 380*90*92MM 36V*15A*250W 5S 0-5 Level

Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
