XDSWIFT4RIG-21BA-13
Size:
Colour:
Baltic
Find a Retailer
Recommended Retail Prices excludes shipping costs, dealer assembly/prep and accessories. Please speak to your nearest store for more information.
Specifications
| Frame Size | 26/13",15" - 27.5/17",19",21" |
| Frame | XDS X6 6061 Alloy |
| Fork | XDS 6061 Alloy, Rigid |
| Handlebar | XDS Alloy 31.8 640mm wide |
| Grip | MTB Rubber |
| Stem | XDS Alloy A-Head 70mm |
| Seatpost | XDS Alloy 31.6 x 350mm with clamp |
| Seat Clamp | Alloy 31.8mm with Quick Release |
| Saddle | MTB Saddle |
| Gear Shifter | Shimano M315 Rapidfire, 2 speed |
| Gear Shifter | Shimano M315 Rapidfire, 8 speed |
| Front Derailleur | Shimano Altus M315 Front Derailleur |
| Rear Derailleur | Shimano TX800SG Rear Derailleur 8-speed |
| Front Brake | Tektro M275 Hydraulic disc with 160mm rotor |
| Rear Brake | Tektro M275 Hydraulic disc with 160mm rotor |
| Freewheel | Shimano HG318 - 8 Speed Casstte, 11-32t |
| Pedal | MTB Plastic with bearings |
| Chainwheel | Prowheel 22/36T steel rings with Alloy 170mm Cranks |
| Chain | 1/2 x 11/128 x 108L |
| Bottom Bracket | Cartridge |
| Headset | Alloy/Steel integrated |
| Front Hub | Alloy 32H Quick Release Disc |
| Rear Hub | Alloy 32H Quick Release, Disc, Freehub |
| Spokes | 14G Steel with brass nipples |
| Tyre | MTB 26 x 2.10, 27.5 x 2.10 all Black |
| Rim | XDS XV21 32H Alloy |
| Bell | Alloy flick |
| Kickstand | Steel |
Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
Bike Size Guide
| Frame Size Number | 13" | 15" | 17" |
| Wheel Size | 26" | 26" | 27.5c |
| Suggested Height | 145-155cm | 155-165cm | 165-175cm |
| Minimum Suggested Inseam | 63cm | 67cm | 70cm |
| A - Seat Tube | 33cm | 38.1cm | 43.2cm |
| B - Seat Tube Angle | 73° | 72° | 72° |
| C - Head Tube Length | 12.5cm | 12.5cm | 12.5cm |
| D - Effective Top Tube | 51.4cm | 54.9cm | 57.8cm |
| E - Chainstay length | 55.48cm | 55.48cm | 55.48cm |
| F - Wheelbase | 43.5cm | 43.5cm | 43.5cm |
| G - Standover | 61cm | 65cm | 68cm |
