Features
Revolutionary X6 Ultralight Aluminum Frame
Experience a revolution in lightweight and durable alloy with the unique XDS engineered X6 Ultralight Aluminum Frame. The X6 is a top-tier hydroformed aluminum frame using the composition of the stiffest aluminum to bring you the lightest, highest quality and top-tier reliability. Co-developed with Central South University Aluminum Research Institute for engineering excellence.
Absorb Rough Bumps
XDS MT30 suspension forks absorb blows from uneven surfaces, keeping yourself and your frame comfortable. XDS MT30 also has a lockout feature for those smooth trail rides.
Shimano Drivetrain
Find the most appropriate gearing ratio for tackling a range of inclines on and off-road with the 21 Speed Shimano Tourney drivetrain. Shift gears easily with Shimano EZ Fire Plus shifter.
Specifications
Frame Size | 26/13",15" - 27.5/17",19",21" |
Frame | XDS X6 6061 Alloy |
Fork | XDS MT30 with Lock out, 100mm travel |
Handlebar | XDS Alloy 31.8 640mm wide |
Grip | MTB Rubber |
Stem | XDS Alloy A-Head 70mm |
Seatpost | XDS Alloy 31.6 x 350mm with clamp |
Seat Clamp | Alloy 31.8mm with Quick Release |
Saddle | MTB Saddle |
Gear Shifter | Shimano EF41 EZ Fire Plus 3 speed |
Gear Shifter | Shimano EF41 EZ Fire Plus 7 speed |
Front Derailleur | Shimano Tourney TY500 front derailleur |
Rear Derailleur | Shimano Tourney TY300 Rear Derailleur 7-speed |
Front Brake | Tektro M280 Mechanical disc with 160mm rota |
Rear Brake | Tektro M280 Mechanical disc with 160mm rota |
Freewheel | SunRace MF-M300 7 speed 14-34T |
Pedal | MTB Plastic with bearings |
Chainwheel | Prowheel 42x34x24T steel rings with Alloy 170mm Cranks |
Chain | 1/2″×3/32″×110L |
Bottom Bracket | Cartridge |
Headset | Alloy/Steel integrated |
Front Hub | Alloy 32H Quick Release Disc |
Rear Hub | Alloy 32H Quick Release, Disc, Freehub |
Spokes | 14G Steel with brass nipples |
Tyre | MTB 26 x 2.10, 27.5 x 2.10 all Black |
Rim | XDS XV21 32H Alloy |
Bell | Alloy flick |
Kickstand | Steel |
Specifications are subject to change at any time and without notice. We recommend contacting your Authorised Reseller before purchasing.
Bike Size Guide
Frame Size Number | 13" | 15" | 17" | 19" | 21" |
Wheel Size | 26" | 26" | 27.5"c | 27.5" | 27.5" |
Suggested Height | 160-170cm | 170-180cm | 180-185cm | 185-190cm | 190+cm |
Minimum Suggested Inseam | 69cm | 73cm | 77cm | 81cm | 84cm |
A - Seat Tube | 33cm | 38.1cm | 43.2cm | 48.3cm | 53.3cm |
B - Seat Tube Angle | 73° | 73° | 73° | 73° | 73° |
C - Head Tube Length | 12.5cm | 12.5cm | 12.5cm | 12.5cm | 12.5cm |
D - Effective Top Tube | 55.48cm | 55.48cm | 59.6cm | 59.6cm | 59.6cm |
E - Chainstay length | 43.5cm | 43.5cm | 43.5cm | 43.5cm | 43.5cm |
F - Wheelbase | 105.72cm | 105.72cm | 109.47cm | 109.47cm | 109.47cm |
G - Standover | 67cm | 71cm | 75cm | 79cm | 82cm |
